Screen Size

55” class (54.64” diagonal)

Panel Technology

IPS

Aspect Ratio

16:9

Native Resolution

1920 x 1080 (FHD)

Pixels(H x V x 3)

6,220,800

Brightness

700 cd/m2

Contrast Ratio

1,400:1

Dynamic CR

500,000 : 1

Color Gamut

72%

Viewing Angle

178°/178°

Color Depth

1.06 Billion

Response Time

8ms (G to G BW)

Running Time

24Hr

Orientation

Portrait & Landscape

HDMI

Yes

DP

Yes

DVI-D

Yes

OPS

Yes

Analog

RGB

RS232C IN

Yes

RJ45 In

Yes

IR Receiver

Yes

USB (USB3.0, USB2.0)

Yes

HDTV Formats

HDMI : 720p, 1080i, 1080p

DP Out

Yes (1), DP1.2a/HDCP1.3

Audio Out

Yes

Temperature Sensor

Yes

OPS PC Power Control

Sync On, Sync On/Off, Disable

Check Screen

Yes

Embedded Template

Yes

Beacon

Yes

Media Share

Yes

SuperSign Server Setup

Signage name, Server IP setting, Server IP Status

Fail Over

USB, RGB, DVI, HDMI, Internal Memory

Lock Mode

USB

Configuration Setup

USB auto Playback

SetID Setup

Manual, Auto

Password Change

Yes

Intelligent Auto

Yes

OSD Portrait Mode

0,90

Content Rotation

0,90

Pivot Mode

Yes

Power On Delay

0 ~ 255

Digital Audio Input

Yes

Wake On LAN

Yes

Local Time Auto Setting

Yes

PM Mode

Yes

Sync Mode

Time sync, Content sync

DST(Summertime Saving)

Yes

HDMI-CEC

Yes

Calibration Mode

Yes

Contents Scheduling

USB, Internal memory

Frameware Update (LAN)

Yes

USB Cloning

Logo image download, Sent to USB, Receive from USB

Wi-Fi

WiFi Dongle Ready

Internal Memory

8GB (System 4GB + Available 4GB)

File Play With USB

Yes

Language (OSD)

English, French, German, Spanish, Italian, Korean , Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues (Europe), Dutch, Czech, Greek

Tile Mode

Yes (Up to 15x15)

Natural Mode @Tile Mode

Yes

Source Selection

RGB, HDMI, DVI, DP, OPS, USB

Brightness/Contrast /Backlight

Yes

Energy Saving

Yes, Off / Minimum / Medium / Maximum / Screen Off

Position/Size

Yes

ISM Method

Normal, Orbiter, inversion, White wash, User Image/Video, Washing Bar

Advanced

Clear White, Dynamic Contrast, Dynamic Color, Noise Reduction, Gamma, Black Level, Skin color, Digital Noise Reduction

Auto Config/Phase

Yes

Key Operation

IR operation, Local key operation

Smart Energy Saving

Yes

Power On Status

Standby, PWR, LST

DPM Select

Yes

Still Image Diagnosis

Yes

Input Label

Yes (PC/DTV)

Time

Clock, On/off Time, Sleep Timer, Power on Delay

VESA™ Compatible

600mm x 400mm

Carton Weight

55.12lbs

Carton (W x H x D)

53.27” x 33.66” x 10.35”

Weight

43.65lbs

(W x H x D)

47.69” x 26.86” x 3.41”

Bezel Width

0.9mm (Top/Bottom/Left/Right)

Optional

Wall Mount (Landscape : WM-L640V, Portrait : WM-P640V) OPS Kit (KT-OPSA), HD Base T(EB-B100)

Basic

Remote Controller, Power cable, DP Cable, Manual, IR Receiver, RS-232C Cable, LAN Cable, Guide Bracket, Screw

Power Supply

100–240V~, 50/60Hz

Typ.

220W

Power Type

Built-in Power

DPM

0.7W

Smart Energy Saving

110W

Power off

0.5W

External Media Player Attachable

Yes (MP500/MP700)

OPS Type Compatible

Yes

Operation Temperature

32°F ~ 104°F

Operation Humidity

10%~90%
