Panel Size

1-Chip DLP 17mm (0.67")

Light Source

Laser

Resolution

WUXGA (1920 x 1200) 16:10 aspect ratio

Light Output (Brightness) ANSI Lumens

8000 (Normal), 5400 (Eco)

Contrast Ratio

20,000:1

Lens

Interchangeable, not included

System Life (Hours)

20,000

Lens Zoom

Powered Zoom x 1.5 (using SD-903)

Lens Focus

Powered Focus (SD-903)

Lens Shift

Motorized (SD-903)

Throw Distance

1.8 - 21.4m (WIDE) / 2.7 - 31.9m (TELE) (using SD-903)

Distance to Width Ratio/ Throw Ratio (:1)

FL-920 Throw 0.38; USL-901A Throw 0.8 - 1.0; SL-902 Throw 1.1 - 1.7; SD-903 Throw 1.6 - 2.4; ML-904 Throw 2.4 - 3.6; LL-905 Throw 3.5 - 5.6; UL-906 Throw 5.5 - 8.8

Diagonal Display Size

50 - 600" (using SD-903)

Speakers

No

Digital Keystone Correction

Horizontal ±60°, Vertical ±40°

Digital Input

HDMI x 2, DVI-D x 1, SDI BNC x 1, HDBaseT x 1

Analogue Input

15-pin Mini-D-Sub x 1, BNC x 1

Video Output

SDI BNC x 1

Audio Input

Not supported

Audio Output

Not supported

RS-232C Control

1 x 9-pin D-Sub

Wireless LAN

No

Wired LAN

RJ45 connector x 1 (shared with HDBaseT)

USB Type A

No

USB Type B

No

Power Supply

AC 100V – 130V (50/60Hz), AC 200V – 240V (50/60Hz)

Operating Power Consumption

845W

Standby Power Consumption

Less than 0.5W

Weight

28kg (without lens)

Dimensions (W x H x D) (Without feet)

500 x 216 x 576 mm

Noise

41dB (Normal), 37dB (Eco)

Supplied Accessories

Power Cord: US Cord for 110v (2.5m) x 1, EURO Cord (2.5m) x 1, Wireless Remote Control unit x 1, AA Battery x 2, RS232C Cable (Cross, Male to Male), RGB Cable (1.8m) x 1, EAC document x 1, Multi-lingual user manual (CD-ROM) x 1, Multi-lingual User Manual (Printed Manual) x 1

Optional Accessories

FL-920 (Ultra Short Throw Lens), USL-901A (Short Throw Lens), SL-901 (Short Throw Lens), SD-903 (Standard Throw Lens), ML-904 (Middle Throw Lens), LL-905 (Long Throw Lens), UL-906 (Ultra Long Throw Lens)

Remote Control

HL03141

Warranty

10,000 hours / 3years (whichever comes first) (for extended warranties please contact your local dealer)
