Panel Size

1-Chip DLP 17mm (0.67")

Light Source

Laser

Resolution

WUXGA (1920 x 1200) 16:10 aspect ratio

Light Output (Brightness) ANSI Lumens

6000 (Normal), 4670 (Eco)

Contrast Ratio

20,000:1

Lens

Interchangeable, not included

System Life (Hours)

20,000

Lens Zoom

Manual Zoom x 1.25 (using SD-63)

Lens Focus

Manual Focus

Lens Shift

Manual

Throw Distance

1.5m - 7m (SD-63 Lens)

Distance to Width Ratio/ Throw Ratio (:1)

1.54 (WIDE), 1.93 (TELE) (using SD-903 lens)

Diagonal Display Size

36 – 380" (using SL-62 Short Thow lens), 36 – 211" (using Standard lens SD-63), 32 – 481" (using long throw ML-64 lens)

Speakers

12W (mono) or 6W x 2 (mono)

Digital Keystone Correction

Horizontal: ±25°, Vertical: ±30°

Digital Input

HDMI x 2, DVI-D x 1, HDBase-T x 1

Analogue Input

1 X Mini-D-sub 15-pin connector

Video Output

15-pin Mini D-Sub x 1

Audio Input

3.5mm Stereo Mini Jack x 1, RCA Jack (L/R) x 1

Audio Output

RCA jack L/R x1

RS-232C Control

1 x 9-pin D-Sub

Wireless LAN

No

Wired LAN

Yes

USB Type A

1 x USB Type A (for PC-less Presentation)

USB Type B

No

Power Supply

AC 100V – 120V (50/60Hz), AC 220V – 240V (50/60Hz)

Operating Power Consumption

700W

Standby Power Consumption

Less than 0.5W

Weight

24.5kg

Dimensions (W x H x D) (Without feet)

521 x 220 x470mm (Excluding lens)

Noise

35db (Normal), 33db (Eco)

Supplied Accessories

Mount cap x 1, Power cord: US cord for 110v (2.5m) x 1, EURO cord (2.5m) x 1, Wireless Remote Control unit x 1, AAA Battery x 2, RGB cable (1.8m) x 1, Wire Remote Cable x 1, 3D Sync Cable x 2, EAC document x 1, EU Recycle Sheet, WEEE Manual, Multi-lingual user manual (CD-ROM) x 1

Optional Accessories

SL-61 (Short Throw Lens), SL-62 (Short Throw Lens), SS-63 (Standard Throw Lens), SD-63 (Standard Lens), ML-64 (Long Throw Lens), LL-65 (Ultra Long Throw Lens)

Remote Control

HL03171

Warranty

10,000 hours / 5 years (whichever comes first) (for extended warranty please contact your local dealer)
