Resolution

Full HD (1920 x 1080)

Display System

1-chip DLP®

Display Device

Size of Effective Display Area

0.65" DLP® chip x 1, aspect ratio 16:9

Number of Pixels

2,073,600 pixels (1,920 horizontal x 1,080 vertical)

Lens (Option)

Zoom

Motorised

Focus

Motorised

Lens Shift

Motorised (V, H)

Lamp Wattage

365W x2

Lamp Life

2000 hours (Normal Mode)/4000 hours (Eco Mode)*

Screen Size

50-600 inch

Brightness

8200 ANSI Lumens

Contrast Ratio

2500:1 (Theatre Mode)

Picture Adjustments

Perfect Fit, Memory function (lens shift, zoom, focus)

Advanced Features

Accentualizer technology, DICOM simulation, Instant stack, Mechanical shutter, Picture by Picture/Picture in Picture, Status monitor, Advanced image processing, HDCR (High Dynamic Contrast Range), Edge blending, Warping, iOS Connectivity, Built-in dual colour wheel, HD Base T, Dual lamp

Network

AMX Device Discovery, Crestron RoomView® (not accessible through the wireless adaptor)

OSD Languages

33

Computer In

Mini D-sub 15-pin connector x 1

Monitor Out

Mini D-sub 15-pin connector x 1

SDI

BNC connector x 1

HDMI 1/2

HDMI connector x 2

DVI-D

DVI-D connector x 1

HDBase T

RJ-45 connector x 1

Video

BNC connector x1

LAN

RJ-45 connector x 1

Wireless

USB Type A x 1

Remote Control In

3.5mm stereo mini connector x 1

Remote Control Out

3.5mm stereo mini connector x 1

Control (RS-232C)

D-sub 9-pin connector x 1

Operating Temperature

0~50°C, 45~50°C: operated in Eco Mode only

Air Filter

Hybrid (up to 15,000 hours)*

Dimensions (WxHxD)

537mm x 170mm x 438mm (21.1" x 6.7" x 17.2") (excluding lens and protruding part)

Weight

Approx. 16.6kg (36.6 lbs.) (excluding lens)

Power Requirements

AC110-120V / 220-240V (50Hz/60Hz)

Maximum Power Consumption

AC110-120V:1,060W / AC220-240V:990W

Accessories

Remote control with batteries, power cord, computer cable,adapter cover, Application CD, user manual (book, CD)

Lamp

DT01731

Ultra short throw lens

USL-901

Short throw lens

SL-902

Standard lens

SD-903W

Middle Throw Lens

ML-904

Long throw lens

LL-905

Ultra long throw lens

UL-906

USB wireless adapter

USB-WL-11N

Projector warranty

3 Years/6 Months** (For education and extended warranties please contact your local dealer)

*1 When the ambient temperature exceeds 45C, the brightness of the lamp is reduced automatically.

disclaimer 3years /6 months

*The stated lamp and filter life refers to the average life expected in ideal operating conditions with usage in accordance with the manual. The majority of, but not all lamps and filters should achieve this figure. **Where a lamp fails within warranty and a replacement lamp is taken, the warranty for the replacement lamp will be a maximum of 6 months (dependent on warranty hours stated).
