Panel

0.96" (2.4cm) DMD x 3

Resolution

WUXGA (1920 x 1200)

Brightness

Normal Mode 13000 ANSI Lumens
Eco Mode 10060 ANSI Lumens

Contrast Ratio

2000:1

Standard Lens

Lens not supplied (see optional lenses)

Lamp

465W x 2 (Normal Mode)/360W x 2 (Eco Mode)

Lamp Life

2000 hours (Normal Mode)/2500 hours (Eco Mode)*1

Diagonal Display Size

100"~400" (2.54m~10.16m) (Standard lens: ML-K04)

Lens Shift

Vertical: -25~+50% (excluding FL-K01 optional lens)
Horizontal: -10~+10% (excluding FL-K01 optional lens)

Number of colours

1.07 billion colours

Focus distance

4.0m~24m (Standard lens: ML-K04)

Distance to width ratio

1.87~2.56 (Standard lens: ML-K04)

Computer compatibility

IBM Compatible VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, WSXGA+, UXGA, WUXGA, MAC 16"

Component Video

525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 1125p(1080p@50/60), 750p(720p@50/60)

3D (DVI)

1920x1080@120Hz, 1920x1080@100Hz, 1920x1080@60Hz, 1920x1200@120Hz, 1920x1200@100Hz, 1920x1200@60Hz

3G SGI

NTSC, PAL, 1035i@60Hz, 1080i@59Hz, 1080i@60Hz, 1080P@30Hz, 1080P@25Hz, 1080i@50Hz, 1080P@24Hz, 720P@60Hz, 720P@50Hz, 1080Sf@25Hz, 1080Sf@30Hz, 1080P@50(3G_A*2), 1080P@59(3G_A), 1080P@60(3G_A), 1080P@50(3G_B), 1080P@59(3G_B), 1080P@60(3G_B)

Plug & Play

DDC2B

Basic functions

Auto signal search

Picture Adjustments

Aspect selection, Mirror reverse image, Progressive scan

Digital Keystone Correction

Vertical ±20°, Horizontal ±35°

Advanced Features

3D display, Edge blend, Framelock, Gamma correction selection, Lamp mode (Normal, Eco, power), Picture by Picture, Picture in Picture, Shutter by remote control, Warp (geometric correction), Dual lamp, DICOM Simulation Mode

Power on & off

Auto off

OSD Languages

English, French, German, Spanish, Japanese, Simplified Chinese, Traditional Chinese, Korean, Portuguese

Digital Input

2 x HDMI (HDCP compatible), 1x DVI-D, 1 x SDI/HDSDI/3G BNC

Digital output

1 x SDI/HDSDI/3G BNC

Computer Input

1 x 15-pin Mini D-sub, 1 x 5 BNC

Video Input

1 x 3 RCA, 1 x 15-pin Mini D-sub, 1 x 5 BNC

USB

1 x USB Type B

3D sync

1 x BNC (in), 1 x BNC (out)

12V trigger

2 x Stereo mini jack

Control

1 x 9-pin D-sub for RS-232C

Network

1 x RJ-45

Power Supply

AC90-143V / AC180-264V (50/60Hz)

Power Consumption/Standby

1250W/<3W (220V AC/5.3A)

Dimensions (W x H x D) (Without feet)

500 x 633 x 270mm (excluding feet and extrusions)

Weight

34kg (excluding lens)

Ambient temperature

Operating: 0~40°C/Storage: -20~60°C

Noise Level

46dB (Normal Mode)/42dB (Eco mode)

Filter

10,000hrs

Certification (CP-WU13K)

UL60950-1/cUL, FCC Part 15 subpart B class A, CE Marking: EN61000-3-2, EN61000-3-3, EN55022, EN55024 (EMC Directive), EN60950-1 (Low voltage directive), WEEE/RoHS/ErP (lot6, lot19) compliant, TUV GS, RCM class A, EAC

Accessories Supplied (CP-WU14K)

Remote control with batteries (HL03051), Power cord, RS-232C cable, EAC document, User manual (CD-ROM & printed sheet)

Replacement lamp

DT01591

Filter set

MU08321 (for front) MU08331 (for rear)

Ultra short throw lens

FL-K01

Short throw lens

FL-K02

Short throw zoom lens

SL-K03

Standard zoom lens

ML-K04

Long throw zoom lens

LL-K05

Ultra long throw zoom lens

UL-K06

Projector warranty

3 Years/6 Months**

Disclaimer (CP-WU13K)

*1. The stated lamp life refers to the average life expected in ideal operating conditions with usage in accordance with the manual. The majority of, but not all lamps and filters should achieve this figure. *2. 3G_A=3G LEVEL A, 3G_B=3G LEVEL B *3. Where a lamp fails within warranty and a replacement lamp is taken, the warranty for the replacement lamp will be a maximum of 6 months (dependent on warranty hours stated).
