Panel Size

3LCD 16mm (0.63")

Resolution

XGA (1024 x 768)

Light Output (Brightness) ANSI Lumens

4200 (Normal), 2814 (Eco-2)

Contrast Ratio

2000:1

Lamp Life (Hours)

5,000 hours (Normal), 10,000 hours (Eco-2)

Lens

Built-in

Lens Zoom

Manual Zoom x 1.2

Lens Focus

Manual Focus

Throw Distance

0.9 - 10.9m

Distance to Width Ratio/ Throw Ratio (:1)

1.5 (Wide), 1.8 (Tele)

Diagonal Display Size

30 - 300"

Speakers

1W Mono

Digital Keystone Correction

Vertical ±30°

Digital Input

HDMI x 1

Analogue Input

15-pin Mini D-Sub x 2, RCA Jack x 1

Video Output

15-pin Mini D-Sub x 1

Audio Input

RCA Jack (L/R) x1

Audio Output

RCA Jack (L/R) x1

RS-232C Control

1 x 9-pin D-Sub

Wireless LAN

No

Wired LAN

No

USB Type A

No

USB Type B

No

Power Supply

AC 100 - 120 V / AC 220 - 240 V (50/60 Hz)

Operating Power Consumption

300W

Standby Power Consumption

Less than 0.5W

Weight

2.9Kg

Dimensions (W x H x D) (Without feet)

320 x 85 x 245mm

Noise

37dB (Normal), 32dB (Eco), 29dB (Eco-2)

Filter Life (Hours)

5,000

Computer

IBM Compatible VGA, SVGA, XGA, WXGA, WXGA+/ SXGA/ SXGA+/ UXGA (compressed), MAC16"

Video

525i (480i), 525p (480p), 625i (576i), 1125i (1080i@50/60), 750p (720p@50/60), 1125p (1080p@50/60)

Supplied Accessories

Power Cable (1.8m) x1, Computer Cable (2m) x1, IR Remote Control Unit x1, AA Batteries x2, CD User Manual x1, Concise User Manual x1

Remote Control

HL03031

Replacement Lamp / Filter

DT01481/ UX38841

Projector/ Lamp Warranty

3 years / 6 months (for education and extended warranties please contact your local dealer.)
